The MK Series 4-wheel electric counterbalance forklift is designed for reliable pallet handling, stacking, and material transfer across warehouses, manufacturing facilities, and logistics operations. With a stable 4-wheel structure, AC drive system, wide-view mast, and ergonomic operator area, it provides dependable electric performance for a wide range of indoor and outdoor applications.
| Model | Capacity | Lift Height |
|---|---|---|
| MK15 / MK20 / MK25 / MK30 / MK35 / MK38 / MK40 | 1500kg / 2000kg / 2500kg / 3000kg / 3500kg / 3800kg / 4000kg | Up to 7000 mm / Up to 7000 mm / Up to 7000 mm / Up to 7000 mm / Up to 7000 mm / Up to 7000 mm / Up to 7000 mm |
Reliable handling for warehouse and factory loads.
Improves visibility for safer pallet handling.
Adjustable controls improve driving comfort.
Supports energy-saving daily operation.
Makes battery replacement and maintenance easier.
Adjustable controls improve driving comfort.
| Specification | MK15 | MK20 | MK25 | MK30 | MK35 | MK38 | MK40 |
|---|---|---|---|---|---|---|---|
| Model | MK15 | MK20 | MK25 | MK30 | MK35 | MK38 | MK40 |
| Operation Type | Seated | Seated | Seated | Seated | Seated | Seated | Seated |
| Load Capacity | 1500kg | 2000kg | 2500kg | 3000kg | 3500kg | 3800kg | 4000kg |
| Lift Height | Up to 7000 mm | Up to 7000 mm | Up to 7000 mm | Up to 7000 mm | Up to 7000 mm | Up to 7000 mm | Up to 7000 mm |
| Mast Type | — | — | — | — | — | — | — |
| Fork Outside Spread | 220–680 mm | 220–680 mm | 244–1050 mm | 244–1050 mm | 250–1075 mm | 250–1075 mm | 250–1075 mm |
| Aisle Width | 2760–2845 mm | 2760–2845 mm | 3754–3884 mm | 3754–3884 mm | 3889 mm | 3889 mm | 3889 mm |
| Battery Specification | Lead-acid: 24V / 300–480Ah; Lithium: 24V / 150–300Ah | Lead-acid: 24V / 300–480Ah; Lithium: 24V / 150–300Ah | Lead-acid: 48V / 500–600Ah or 80V / 500Ah; Lithium: 48V / 300–460Ah or 80V / 300–600Ah | Lead-acid: 48V / 500–600Ah or 80V / 500Ah; Lithium: 48V / 300–460Ah or 80V / 300–600Ah | Lead-acid: 80V / 400–500Ah; Lithium: 76.8V / 230Ah or 80V / 300–600Ah | Lead-acid: 80V / 400–500Ah; Lithium: 76.8V / 230Ah or 80V / 300–600Ah | Lead-acid: 80V / 400–500Ah; Lithium: 76.8V / 230Ah or 80V / 300–600Ah |
The MK Series is a new-generation 4-wheel electric counterbalance forklift designed for light, medium, and heavier material handling applications. Covering capacities from 1500 kg to 4000 kg, the series provides flexible options for warehouses, manufacturing plants, logistics centres, container handling areas, and indoor-outdoor material transfer.
The forklift uses a front single-drive mechanical differential system, full hydraulic steering, and a maintenance-free AC drive system. Its high-ratio gearbox provides strong climbing and traction capability, helping the truck perform reliably in a wide range of working conditions.
For stability and operator comfort, the drive motor is arranged in an advanced transverse layout, and the battery is positioned low in the truck body to reduce the centre of gravity. The ergonomic operator area includes an adjustable steering wheel and adjustable seat, allowing operators to work with improved comfort and control.
The MK Series also focuses on safe and efficient handling. The wide-view mast design improves visibility, while lift limit protection, automatic lowering speed control, lowering buffer, regenerative braking, reverse braking, ramp anti-rollback, LED lighting, and OPS operator presence monitoring help support safer daily operation.
With optional side battery removal, side shift, fork positioner, and lift buffering configurations, the MK Series can be adapted to different warehouse layouts and handling requirements. It is a practical electric alternative to internal combustion forklifts for businesses seeking lower emissions, reduced maintenance, and reliable handling performance.
